| Machine Weight | 590 lb (268 kg) |
|---|
| Weight Stack(s) | 295 lb (138 kg) |
|---|
| Max User Weight | 300 lb (136 kg) |
|---|
| Cables | 7×19 strand construction, lubricated, nylon-coated cable meets U.S. military specifications |
|---|
| Instructional Placards | Easy-to-follow instructions illustrate proper use and muscles trained; Axis of rotation marked with red indicator to help cue correct alignment |
|---|
| Belts and Pulleys | 4-1/2″ (11 cm) and 6″ (15 cm) diameter fiberglass-impregnated nylon pulleys feature sealed bearings |
|---|
| Cushioning | Pads are molded with radius on edge for improved comfort; All edges are stitched to eliminate any folds in the material that would limit durability |
|---|
| Shrouds | Standard rear shroud on SE models; Optional full front shroud on SE models |
|---|
| Weight Plates and Guide Rods | Solid-steel weight plates. Top weight plate is fitted with self-lubricating bushings; 7/16″ (11 mm) diameter weight selector pin magnetically locks in place and is connected to stack to prevent loss; Drop down incremental weight system (standard on SE models) |
|---|
| Adjustments | Roller mechanism on seat adjustment provides smooth operation |
|---|
| Foot Platforms | Polyethylene spray-coated for impact, corrosion, and abrasion resistance |
|---|
| Frame Description | Each frame receives an electrostatic powder coat finish to ensure maximum adhesion and durability; Standard rubber feet protect base of the frame and prevent the machine from slipping; 11-gauge steel frame ensures maximum structural integrity |
|---|
| Hand Grips | Grips retained with aluminum collars, preventing them from slipping during use; Hand grips are an extruded thermo rubber compound that is non-absorbing and wear-and-tear resistant |
|---|
